FILN 19MM Lamp Push Button Switch Waterproof Lamp Switch
- Waterproof class: IP67 Button Switch
- Name:Lamp Push Button Switch
- Model: FLPQ19-10HEWM / FLPQ19-10FEWM
- Head Type: Flat Head / High Head
- Mounting Size: 19MM / 0.74″
- Switching Functions: Momentary / Latching switch
- Contact Configuration: I NO Push Button Switch
- Rated Voltage: 10A push button switch
- Voltage Options: 2V, 3V, 5V, 6V, 12V, 24V, 110V, 120V, 220V, 230V, 240V, 250V, 380V
- Light Color: Red, Blue, Green, Yellow, White
- Materials: Copper, Stainless steel, Zinc alloy
- Download Certification: UL, CE, CCC,RoHS,IP67
- Wire specification: AGW22
- Email:sales2@filn.com.cn
- Download PDF: 19MM Lamp Push Button Switch
19MM Lamp Push Button Switch Product Drawings:
19MM Lamp Push Btton Switch Introduction
A Custom Solution Born at KES 2018
The innovative lamp push button switch by FILN was custom-designed to meet the specific demands of a South Korean client in the medical beauty equipment industry, presented at the KES exhibition in 2018. Previously, their switches, typically threaded, required significant manual effort to install, a costly process given the high labor costs in South Korea. FILN’s design revolutionized this by introducing a switch that effortlessly snaps into place, optimizing efficiency and reducing costs.
Advantages of the Push Button Lamp Switch
1.Easy installation:The lamp with push button switch boasts a clip-in feature allowing for quick, tool-free installation on control panels, drastically enhancing efficiency and cutting down on labor expenses.
2.Versatile Design Options
FILN’s push button switch lamp comes in a variety of colors, catering to diverse aesthetic preferences, including but not limited to red, green, yellow, blue, and white.
3.IP67 Waterproof Rating
The 19mm lamp push button switch is designed with an IP67 waterproof rating, ensuring its reliability for outdoor use or in any environment exposed to water.
4.Customizable Features
Customization is key with FILN’s lamp switch, offering features such as locking mechanisms or reset functions tailored to your requirements.
5.Certified Quality Assurance
With certifications like UL, CE, and TUV, FILN lamp switches guarantee quality, allowing users to operate with confidence.
FILN’s dedication to innovation, customer satisfaction, and quality assurance is evident in their push button lamp switch—crafted for performance, built for reliability.
19MM Lamp Push Button Switch Product Specifications:
| Production Series | FLPQ19-10HEWM | Light Guide Button | PC plastic |
| Button Shape | round | Actuator | 304 Stainless steel |
| Button LED Color | Red, Blue, Green, Yellow, White | Housing Sleeve | H59 nickel plated brass/304Stainless steel |
| Mechanical Life | The 500 thousand time | Button Pin | 22AWG PVC wire(0.3MM2) |
| Electrical Life | The 100 thousand time | Rubber Ring | SIL silica gel |
| Protection Level | IP67 push button switch | Nut | H59 nickel plated brass |
| Rated Voltage | 36V（DC） 250（AC） | Housing | PA66+GF20% nylon |
| Rated Current | 5A（DC）5A（AC） | Light Source | LED button switch |
| Rated Power | 180W（DC）1250W（AC） | Resistor | Metal film |
| Operating Temperature | -25℃~+85℃ | Contact | AgCdO12 |
Tailored Push Button Lamp Switch Solutions
FILN: A 20-Year Expertise in Switch Manufacturing
FILN SWITCH FACTORY is a professional manufacturing plant with two decades of experience in producing switches. They offer customized solutions, including various types of push button lamp switches to meet diverse needs.
- 1. Customization For Cost-Effectiveness
If cost reduction is your goal, FILN is committed to designing a push button switch with lamp that aligns with your specific requirements and application scenarios.
- 2. No Minimum Order Quantity
Should you need a smaller quantity of the LAMP PUSH BUTTON SWITCH, worry not—FILN imposes no minimum order quantity, ensuring flexibility and client convenience.
3. Versatile Customization Options
LAMP SWITCH customization options extend to various voltages and colors, providing a wide array of choices to fit any design scheme or functional requirement.
- 4. Compatibility And Convenience
The tail of the lamp with push button switch is designed to connect with any terminal, including cold-pressed terminals, 2.54, or 6.3 types, facilitating ease of installation and use.
FILN stands out with its dedication to offering personalized services and adaptable products, ensuring smooth communication and Efficient solutions.
How To Wire A 19MM Lamp Push Button Switch ?
first of all we need to know that the 19MM Lamp Push Button Switch has 4 pins. In which the red line (C) closest to the power supply and the black line (NO) far from the power supply are the switch pins, the other two red lines and black lines are light pins, the light pins are regardless of positive pole or negative pole.—There are two types of wiring, see the picture below.
What’s the first way for the button connection ？
1.The positive pole of the power supply is connected to the switch C pin red wire and the LED lamp pin red wire (+) , and the other NO pin black wire is connected to the positive pole of the bulb device.
2.Connect the negative pole of the power supply to the negative pole of the bulb deviceand the LED lamp pin black wire(-).
19MM Lamp Push Button Switch function:
The Lamp Push Button Switch is locked and the bulb device starts.
The Lamp Push Button Switch is reset, the bulb device is turned off and the light is always on.
What’s the second way for the button connection ？
1.The positive pole of the power supply is connected to the C pin red wire of the switch,and the other NO pin black wire is connected to the LED light pin red wire (+) and the positive pole of the bulb device.
- Connect the negative pole ofthe powersupply to the negative pole of the bulb device and the LED lamp pin black wire (-).
19MM Lamp Push Button Switch function:
The Lamp Push Button Switch is locked and the light is on, and the bulb device starts.
The Lamp Push Button Switch reset light is off, and the bulb device is turned off.
Push Button Lamp Switch Application Environment
19MM Waterproof Lamp Push Button Switch is a button switch with waterproof function, its application environment includes industrial equipment, electronic equipment, etc. This switch has excellent waterproof performance, and can effectively prevent moisture into the switch inside, so as to ensure the stability and reliability of the switch in various environments.
In industrial equipment:19MM Waterproof Lamp Push Button Switch can be used to control the operation and stop of the machine.
In an electronic device: it can be used to control the switch of the circuit to enabling power control of the device. In the circuit board, it can be used to connect and disconnect the circuits, thus enabling the control of the equipment.
In LED lights:it can be used to control the brightness and brightness changes of the lamp.
In Coffee machine: it can be used to control the opening and closing of the coffee machine.
In a Electric stove: it can be used to control the power and time of the Electric stove.
